-22%

Atlantic-Oase Pump Vaults

Sku: AO-74235
Vendor: Atlantic-Oase
Type: Water Basins
Barcode: 727429012017

$329.99

~~$422.98~~

Model: 3900 GPH

Product variants

Usually ships within 1-2 business days.

Price Match Guarantee. Read more.

Return within 30 days of purchase.

Atlantic-Oase Pump Vaults

$329.99

~~$422.98~~

Information

Pump Vaults house and protect the pumps and plumbing of underground water storage and circulaton systems. Atlantic's newly redesigned Pump Vaults occupy the same footprint as Eco-Blox for simplified installation within a rectangular basin. Vaults are rotomolded of virtually indestructible polyethylene for long, worry-free service. Extremely strong low profile vault lids fit all sizes, support gravel and foot traffic and can be removed without gravel falling in. Flat panels accommodate up to 3" plumbing and auto fills.

Either slotted side of Vault handles double the rated flow so one side can be blocked by liner without effecting capacity
Pump vault extensions increase the height of the vault in deeper, larger basins, with each extension the height of one Eco-Blox
All Vaults accommodate two or more pumps for versatility
Remote Pump Vault allows submersible pump location outside of lined reservoir

Technical Specifications

Item	AO-74235	AO-89583	AO-89584	AO-90162	AO-89585
Model	PV1700	PV7500	PV15000	PVRI	PVEXT
For Use With	#74234 - ECOBLOX	#89662 - ECOBLOX-SMALL	#74234 - ECOBLOX	Remote Inline Pump Applications	#89583 - PV7500, #89584 - PV15000
Max Pump Flow	3900 gph	7500 gph	15000 gph
Opening	10"	12.25" x 14.75"
Discharge	1.5" & 2" step outlets	1.5" & 2"	2" & 3"
Dimensions	17"W x 12"D x 22½"H	27"L x 16"W x 20¾"H	27"L x 16"W x 27"H	27"L x 16"W x 18⅜"H	27"L x 16"W x 18⅜"H
Warranty	Lifetime

Resources

Instruction for Pond-Free

Opening Your Pond-free Waterfall

How to Winterize your Pond-free Waterfal

Free 3D Viewer Download

3D Model - PV1700

Technical Drawings Pump Vaults
